相机汇总表
| 订货编号 | 产品型号 | 像素数(万) | 帧速/最大像素规格 | 像素尺寸 | 芯片 | 适配器 | 颜色 |
|---|---|---|---|---|---|---|---|
| UCMOS系列相机参数规格 | |||||||
| TP600350A | UCMOS00350KPA | 35 | 30fps//640X480 | 5.6X5.6 | 1/4 | 0.37X | 彩色 |
| TP601300A | UCMOS01300KPA | 130 | 18fps//1280X1024 | 3.6X3.6 | 1/3 | 0.37X | 彩色 |
| TM601300A | UCMOS01300KMA | 130 | 30fps//1280X1024 | 5.2X5.2 | 1/2 | 0.5X | 黑白 |
| TP602000A | UCMOS02000KPA | 200 | 8fps//1600X1200 | 3.2X3.2 | 1/3.2 | 0.37X | 彩色 |
| TP602000B | UCMOS02000KPB | 200 | 16fps//1600X200 | 3.2X3.2 | 1/3 | 0.50X | 彩色 |
| TP603100A | UCMOS03100KPA | 310 | 8fps//2048X1536 | 3.2X3.2 | 1/2 | 0.50X | 彩色 |
| TP605100A | UCMOS05100KPA | 510 | 5fps//2592X1944 | 2.2X2.2 | 1/2.5 | 0.50X | 彩色 |
| TP608000A | UCMOS08000KPA | 800 | 1.9fps//3264X2448 | 1.67X1.67 | 1/2.5 | 0.50X | 彩色 |
| TP609000A | UCMOS09000KPA | 910 | 1.9fps//3488X2616 | 1.67X1.67 | 1/2.4 | 0.50X | 彩色 |
| TP610000A | UCMOS10000KPA | 1000 | 1.9fps//3584X2748 | 1.67X1.67 | 1/2.3 | 0.50X | 彩色 |
| TP614000A | UCMOS14000KPA | 1400 | 1.8fps//4096X3288 | 1.4X1.4 | 1/2.3 | 0.50X | 彩色 |
| TP8001400A | EXCCD01400KPA | 140 | 15fps//1360X1024 | 6.45X6.45 | 2/3 | 0.75X | 彩色 |
| TM8001400A | EXCCD01400KMA | 140 | 15fps//1360X1024 | 6.45X6.45 | 2/3 | 0.75X | 黑白 |
| TM800300A | EXCCD00300KMA | 30 | 72fps//640X480 | 5.6X5.6 | 1/4 | 0.37X | 黑白 |
| TP705200A | UHCCD05200KPA | 520 | 4fps//2592X1944 | 2.78X2.78 | 1/1.8 | 0.75X | 彩色 |
| TP705100A | UHCCD05100KPA | 510 | 5.5fps//2448X2050 | 3.45X3.45 | 2/3 | 0.75X | 黑白 |
| TP705000A | UHCCD05000KPA | 500 | 4.5fps//2560X1920 | 3.4X3.4 | 2/3 | 0.75X | 彩色 |
| TP703100A | UHCCD03100KPA | 310 | 6fps//2048X1536 | 3.45X3.45 | 1/1.8 | 0.75X | 彩色 |
| TP702000A | UHCCD02000KPA | 200 | 10fps//1600X1200 | 4.4X4.4 | 1/1.8 | 0.75X | 彩色 |
| TP701400A | UHCCD01400KPA | 140 | 12fps//1360X1024 | 4.65X4.65 | 1/2 | 0.75X | 彩色 |
| TM701400A | UHCCD01400KMA | 140 | 12fps//1360X1024 | 4.65X4.65 | 1/2 | 0.75X | 黑白 |
| TP700800A | UHCCD00800KPA | 80 | 16fps//1024X768 | 4.65X4.65 | 1/3 | 0.75X | 彩色 |
SCMOS系列相机参数规格
| TP500350A | SCMOS00350KPA | 35 | 30fps/640X480 | 5.6X5.6 | 1/4 | NA | 彩色 |
| TP501300A | SCMOS01300KPA | 130 | 7.5fps/1280X1024 | 3.6X3.6 | 1/3 | NA | 彩色 |
| TP502000A | SCMOS02000KPA | 200 | 5fps/1600X1200 | 2.8X2.8 | 1/3.2 | NA | 彩色 |
| TP503000A | SCMOS03000KPA | 300 | 3fps/2048X1536 | 2.2X2.2 | 1/2.7 | NA | 彩色 |
| TP505000A | SCMOS05000KPA | 500 | 2fps/2592x 1944 | 2.2X2.2 | 1/2.5 | NA | 彩色 |
